Lamptron FC5V2 12ways PWM Fan Control
Details
Product:Lamptron FC5V2 12ways PWM Fan Control
Lamptron FC5V2 12ways PWM Fan Controller(12-Ways PWM,60 watt/channel,7 colors readout)
Unique Selling Point:
l 12-Ways PWMs
l 60 watt/channel
l 7 colors readout
Product introduction:
Lamptron listens to the call of users worldwide begging to provide a fan control which can handles more PWM fans one-for-all in today’s higher and higher power consumptions era. With the Lamptron design team working closely with suggestions by users like you, we perfected a fan controller that allows a person to connect over 12pcs PWM fans together to control them all. We also added a function which allows users to change the readout color of not one or two but seven different colors! With the readout in the LCD display with the choices of Celsius, Fahrenheit, or Voltages. Lamptron FC5V2 PWM Fan Control will be your one-stop perfect PWM Fan Controller.
FEATURES:
l ü High Power PWM Fan Control
l 4 channels.12 ways. One-for-All.
l ü 60Watt per channel(high-power)
l 0-100% adjustable
l 0% shutdown
l Manual Control
l 7-color readout
l ü Knob Control, easy to use
SPECIFICATION:
| Controller Dimension | 148.5 x 42.5 x 75 mm (W x H x D) |
| Power Output | Up to 60 watts/channel |
| Control Channels | 4 Channel,12 ways |
| DC Input | +12V |
| DC Output | +12VDC |
| Compatibility | PWM Fans |
| Control Mode | Manual Control |
| Changeable Display Color | Red, Yellow, Green, Cyan, Blue, Purple, White |
Order information:
| Part Number | EAN | Product Name | Description |
| LAMP-PFC5S | 6900628404614 | Lamptron PWM Fan Control FC5V2,Silver | Lamptron PWM Fan controller FC5V2,Silver,High Power output,12 ways,Backlight color-changeable |
| LAMP-PFC5B | 6900628404621 | Lamptron PWM Fan controller FC5V2,Black | Lamptron PWM Fan controller FC5V2,Black,High Power output,12 ways,Backlight color-changable |
