Side panel vertical Display Mounted Computer Case-- SDM363
Details
Title:
LamptronSide panel vertical Display Mounted Computer Case-- SDM363
FrontScreen display spec：
- model：24.6mm(W) * 131.7(H) * 205.3(L)
- Display size：8〞
- Color TFT-LCD
- Colors：16.7M
- Resolution：1280*800
- Response Time：30ms(Typ.)
- Brightness：300cd/m2(Typ.)
- Contrast Ratio：1000（Typ.）
- I/O：MINI-HDMI*1(Video Signal)
- TYPE-C*1
- Refresh Rate(max.)：60Hz
- Working Temperture：0-50℃
- model：219.2mm*55mm(screen)
- Display size：8.8〞
- Color TFT-LCD
- Colors：16.7M
- Resolution：1920*480
- Response Time：30ms(Typ.)
- Brightness：300cd/m2(Typ.)
- Contrast Ratio：1000（Typ.）
- I/O：mini-HDMI*1(Video Signal)
- Power：Micro USB
- Refresh Rate(max.)：60Hz
- Working Temperture：0-50℃
- Dimension:205mm (W) * 347.5(H) *440mm(D) (Vol: 35.4L)
- Depth does not include the PCI brackets outside the chassis, height does not include case stand
- 205mm (W) * 363mm(H) * 452mm(D) (overall size)
- Material：0.6mm+0.7mm steel panel
- Drive Bay：2.5〞SSD*3+3.5〞HDD*1
- Motherboard：ATX / M-ATX
- PCI expansion slots：4
- Front I/O：USB3.2 Gen 2 Type-C*1 / USB3.0*1/Audio & Mic*1
- Power supply support：ATX
- CPU cooler support：168mm
- Graphics card support：330-400mm
- Fan mounting position：Top 120mm*3 or 140mm*2；Rear 120*1mm；Bottom 120mm*3 or 140mm*2；Front 120mm*1
- Radiator support： Top 240/280/360*1 ；Rear 120*1 ； Bottom 240/360*1
- Weight: Net 7.00KG
Order information:
| PartNumber | EANCode | Productname | Description |
| LAMP-SDM363MW | 6900628223376 | SDM363 MESH White | Side panel vertical Display Mounted Computer Case； 452*205*363 - White |
| LAMP-SDM363MB | 6900628223383 | SDM363 MESH Black | Side panel vertical Display Mounted Computer Case ； 452*205*363 - Black |
